5.5HP Gasoline Engine Mini Rotary Cultivator

[Search Related Products]

5.5HP Gasoline Engine Mini Rotary Cultivator

Model SR1Z-550
Engine model SR1P64F/P
Engine type OHV 25¡ãSingle cylinder, forced air cooling, 4-stroke
Bore *stroke(mm) 64*42
Starting system Recoil start
Rated output(kW) 2.1
Rated rotary speed(r/min) 3600
Tilling depth(cm) ¡Ý10
Tilling scope(cm) 55
Working speed(m/s) 0.1~0.3
Working performance(hm2/h.m) ¡Ý0.02
Fuel consumption(kg/hm2) ¡Ü40
Driving Mode Gear transmission
Connection mode Straight
Designing rotary speed(r/min) 112
Max Radius of gyration(mm) 150
Amount of blades 16
The model of rotary blade No. 2 blade
Tiller size (mm) 1200*550*800
Package dimensions(mm) 720*385*590
Loading quantity(20/40/40HQ) 192/384/384
N.W(kg) 35
