ZDLY Electric Small Flow Control Valve
[Search Related Products]
ZDLY - Electric small flow control valve
Advantage: small size, light, simple installation and maintenance
Application: used to regulating small flow liquid, vapor etc.
Nominal dimension (mm) | G1/2' | G3/4' | ||||||
Seat diameter (mm) | 1.5* | 3 | 4 | 5 | 6 | 7 | 8 | 9 |
Flow coefficient Kv | 0.0025 | 0.08 | 0.12 | 0.20 | 0.32 | 0.50 | 0.80 | 1.00 |
Rated travel (mm) | 10 | |||||||
Rangeability | 30:1 | |||||||
Nominal pressure | 6.4, 1.0 MPa | |||||||
Valve core | Single seat plunger type | |||||||
Valve body | 1Cr18Ni9Ti、316、316L, corrosion resisting alloy | |||||||
Valve seat | 1Cr18Ni9Ti、316、316L, corrosion resisting alloy | |||||||
Packing | PTFE, flexible graphite | |||||||
Diaphragm | NBR | |||||||
Flow characteristics | Linear | |||||||
Action type | Electric to open, electric to close | |||||||
Working temperature | Ordinary model:-40~230<C, Radiation model:230~450<C, Special ordering:450~600<C | |||||||
Flange standard | JB78-59, JB79/59, JB/T79.1-94, JB79.2-94, ANSI, JIS, DIN | |||||||
Control signal | 4~20mA, DC; 1~5V, DC; 0~10V, DC (related with actuator) | |||||||
Power supply | 220V, AC, 50Hz; 380V, AC, 50Hz (related with actuator) |
Note: 1) Pls contact with us when working temperature, pressure, and dimension are not list in the table
2) Special order for flow coefficient <0.08
