CPT-165A Table Model Marine Compass

CPT-165A Table Model Marine Compass

CPT-165A Table Model Marine Compass is a sort of liquid compass suitable for small and medium sized vessels. It completely meets the national standard GB/T 14108-2011 ( General Technical Terms of Marine Magnetic Compass Class A ). So, you can trust the quality of our products. This compass possesses beautiful shape, high precision, simple operation, reliable performance etc. If you’re interested our compass, please feel free to contact us.

Specifications

Project	Data
Dial Diameter	Φ 165mm
Dial Graduation	0°-360° 1° for each grid
Operation Temperature	-25°C~+60°C
Indicating Deviation(H=35µ T, T=20±3°C)	≦0.5°
Half Period (H=34µ T, T=20±3°C)	≧8.62S
Friction Deviation (H=34µ T, T=20±3°C)	≦0.09°
Main Semicircle Self Heterodyne Correcting Energy	1°~ 45°
Quadrant Self Heterodyne Correcting Energy	0.5°~10°
Inclining Heterodyne Correcting Energy	-75~ +75µT
Lighting Power	AC 220V, DC 24V
Outline Dimension	750×326×570mm
Diameter of Mounting Holes	pitchrow 270, aperture Φ12
Weight	23KG

Features

1. Beautiful shape

2. High precision

3. Suitable for small and medium sized vessels

4. Long service life

CPT-165A Table Model Marine Compass

Model: CPT-165A
