Hydraulic Swing Demolition and Sorting Grab

Hydraulic Swing Demolition and Sorting Grab

Hydraulic swing demolition & sorting grad needs to be equipped with 2 sets of hydraulic valve and pipeline . Cylinders adopt the hydraulic one-way control valve to keep the grab stable and tight. It is for grasping the construction remainsŁ¬industry material and wasteŁ¬the massive tough mud and stone.
Hi-sea provides
1. Free grab design;
2. Designs to customer specification, including volume and unladen weight;
3. Assembly and commissioning by SHYP's specialist technicians;
4.Acceptance testing including certification such as BV, LRS, GL, DNV, ABS, and etc.

Specification:

Machine Tonnage

Description

Width(mm)

Max.Opening ranging(mm)

Weight(Kg)

Material

6-10T

Demolition & sorting grab

640

1300

540

Q345B+Hardox400

11-16T

Demolition & sorting grab

800

1540

840

Q345B+Hardox400

17-20T

Demolition & sorting grab

1000

1880

1000

Q345B+Hardox400

21-24T

Demolition & sorting grab

1150

2140

1300

Q345B+Hardox400

25T30T

Demolition & sorting grab

1200

2200

1500

Q345B+Hardox400

31-35T

Demolition & sorting grab

1250

2250

1700

Q345B+Hardox400

36-40T

Demolition & sorting grab

1300

2300

2000

Q345B+Hardox400

41-45T

Demolition & sorting grab

1400

2350

2200

Q345B+Hardox400


Hydraulic Swing Demolition and Sorting Grab
