Marine Crane:
Marine crane is designed especially for oil platform, platform supply vessel, barge etc. Based on the design consideration of API-2C, marine cranes can be in the working condition of inboard lift, outboard lift and personnel lift.
The crane can be equipped with:
-
Cab air-conditioning system
-
Suspension arm projection lamp
-
Aircraft Obstruction Beacon and Suspension Arm Projection Lamp
-
Anti-explosion
-
Constant tension system
-
Electromotor or diesel drive
-
Touch screen display function
-
Sea state selection function
-
Hanged man function
-
Certificates from CCS, DNV, ABS, GL, LR, BV,RINA, NK, KR and other classification societies
Main specification:
| Model | Offshore hoisting load¡Áradius(t¡Ám) | Onboard hoisting load¡Áradius(t¡Ám) | Hoisting load¡Áspeed(t¡Ám.min) | Whip load¡Áradius(t¡Ám/min) | Luffing time(s) | Slewing speed(m/min) | Driving power(kw) |
| HO5-15P | 5¡Á15 | 5¡Á15 | 5¡Á30 | - | CL:70 | 0.8 | 75 |
| HO15-10(8.5-18)P |
15¡Á10
8.5¡Á18 |
15¡Á10
8.5¡Á18
|
15¡Á20 | 3¡Á20¡Á30 | CL:130 | 1 | 160 |
| HO25-35P | 25¡Á35 | 25¡Á35 | 25¡Á20 | - | CL:130 | 0.5 | 315 |
| HO15-15P | 15¡Á15 | 15¡Á15 |
15¡Á18
3¡Á26 |
- | RL:100 | 1.5 | 110 |
| HO16-25P | 16¡Á25 | 16¡Á25 | 16¡Á18 | - | RL:100 | 1 | 200 |
| HO20-16(5-30.5)P |
20¡Á16
5¡Á30.5 |
20¡Á22
7.5¡Á30.5
|
20¡Á10
1¡Á13 |
5¡Á32¡Á30 | RL:160 | 1 | 224 |
| HO30-12(11-30.5) |
30¡Á12
11¡Á30.5 |
30¡Á17
15.5¡Á30.5
|
30¡Á30 | 5¡Á32¡Á70 | RL:130 | 1 | 315 |
| HO20-16(5-30.5)P |
20¡Á16
5¡Á30.5 |
20¡Á22
7.5¡Á30.5
|
20¡Á10
1¡Á13 |
5¡Á32¡Á30 | RL:160 | 1 | 224 |
| HO30-12(11-30.5)P |
30¡Á12
11¡Á33.5 |
30¡Á17
15.5¡Á33.5
|
30¡Á30 | 5¡Á32¡Á70 | RL:130 | 1 | 315 |
| HO40-102(11-36.5)P |
40¡Á10
11¡Á36.5 |
40¡Á14
15.5¡Á36.5
|
40¡Á30 | 5¡Á38¡Á70 | RL:130 | 0.8 | 400 |
| HO50-15(15-33.5)P |
50¡Á15
15¡Á33.5 |
50¡Á15
15¡Á33.5
|
50¡Á18 | 10¡Á36¡Á60 | RL:130 | 0.8 | 350 |
| HO70-15(30-45)P |
70¡Á15
30¡Á45 |
70¡Á21
40¡Á45
|
70¡Á18 | 20¡Á48¡Á67 | RL:180 | 0.85 | 650 |
| HO80-10(12-45)P |
80¡Á10/12¡Á45(n=4)
40¡Á23/14¡Á45(n=2) |
80¡Á10/12¡Á45(n=4) 40¡Á23/14¡Á45(n=2)
|
80¡Á9(n=4)
40¡Á18(n=2) |
5¡Á47.5¡Á90 | RL:150 | 0.6 | 336 |
|
Note:
1.The driving voltage:380V/50Hz ac/3 Ph or 440V/60Hz ac/3 Ph or diesel engine. 2.The parameter table is only for reference, specifications user requirements can be designed. 3.RL-steel rope luffing,CL-oil cylinder luffing. |
Model explain:HO5-15P
1. HO-Hydraulic Offshore Crane 2. 5-SWL 3.15-Max. working radius 4. P-Offshore pedestal crane |
||||||
