UHMWPE Lighthouse

[Search Related Products]

UHMWPE Lighthouse

UHMWPE Lighthouse

UHMWPE lighthouse is a tower shaped luminous beacon fixed near the waterway. Its main function is to be used for guiding ship sailing or indicating dangerous area, usually used to mark dangerous coast, dangerous sandbar, reefs or channels leading to the port.

Features of UHMWPE Lighthouse

1. High Impact Resistance: Having 2 million more average molecular weight

2. Stable Chemical Performance

3. High Corrosion Resistance

4. Self-lubricated

5. Maintenance Free

6. Long Service Life

7. Easy Installation and Convenient Transportation

8. Great Anti-typhoon Ability

Components of UHMWPE Lighthouse

1. Pillar

2. Ladder(inner or outside)

3. Foundation

4. Guard Ring

5. Working Platform

6. Solar Panel

7. Battery Box

8. Workbench Ring

9. Lightning Rod

Specification of UHMWPE Lighthouse

1. Material: Ultra High Molecular Weight Polyethylene Pipe

2. Application: coast, harbor or river etc.

3. Beacon Diameter: 0.8m~1.5m or as requested

4. Total Height: 4.5~15m or as requested

5. Wind Resistance Grade: Grade 17 typhoon with wind speed 60m/s

6. Color: Red, Green, Yellow, Black, White etc.

7. Service Life: 50 years

8. Certificate: CCS/IALA/ISO9001

Basic Parameters for Reference

Type

Pillar Diameter(mm)

Height(m)

Height per Node(m)

Weight per Node(kg)

Platform Diameter(m)

HSD600

600

3~6

0.5~1.5

18~56

0.6~2.0

HSD800

800

3~6

0.6~1.5

39~98

0.8~2.2

HSD1000

1000

4.0~10.0

1~2.0

102~204

1.0~2.5

HSD1200

1200

6.0~12.0

1~2.0

167~335

1.2~2.6

HSD1500

1500

8.0~15.0

1.5~3.0

198~397

1.5~3.0

Our Service: we supply both the standard products and the customized products produced according to customer¡¯s special requirements. We aim to provide the best quality products and the excellent service. If you have any questions, please feel free to contact us.
