Container Flush ISO Foundation

Container Flush ISO Foundation

Container flush ISO foundation are usually welded on the bottom or cover of hatch, and used with single cone or twist lock to fix the bottom container. And all the items are proved by major classification society. And quality control program ensure to meet client’s requirement strictly.

Product Details:

1. Material: Structural steel

2. Type: Single type

3. Surface treatment: Hot dip galvanized

4. Finish: Shop primer

5. Application: Container, shipping

6. Weight: 7.3kg

7. M.B.L tension: 500KN

8. M.B.L shear: 420KN

9. M.B.L compression: 2000KN

10. All items are proves by major classification society

Our scope of container fittings are the follows:

D-ring, Lashing plate, Raised ISO foundations, Dovetail foundations, Flush sockets, Sliding foundations, Guide cone, Guide block, Turnbuckles, Lashing rods, Extension rods, Manual twistlocks, Semi-automatic twistlocks, Midlocks, Sliding twistlocks, Bridge fittings, Single stackers, Double stackers, Hanging stackers, , ETC.

Sketch of the container flush ISO foundation

Container Flush ISO Foundation HSCF20
