E317L-16 Stainless Steel Electrode

[Search Related Products]

E317L-16 Stainless Steel Electrode

E317L-16 Stainless Steel Electrode

GB E317L-16 AWS E317L-16

Introduction: E317L-16 is a kind of ultra-low-carbon Cr18Ni12Mo3 stainless steel electrode with lime-titania type coating. The carbon content of the deposited metal is lower than or equal to 0.04%. It has excellent heat-resistance, corrosion-resistance, crack-resistance and blowhole-resistance. Its corrosion-resistance is especially more excellent than that of A022. It has excellent welding performance. The coating has red-resistance and high strength. AC/DC.


Uses: Used for welding ultra-low-carbon 00Cr18Ni12Mo3 stainless steel, and also used for welding Cr stainless steel which does not need heat treatment after welding, composite steel and dissimilar steel.


Chemical Composition of Deposited Metal (%)

Chemical Composition
C
Mn
Si
S
P
Cu
Ni
Mo
Cr
Guarantee Value
¡Ü0.04
0.5~2.5
¡Ü0.90
¡Ü0.030
¡Ü0.040
¡Ü0.75
12.0~14.0
3.00~4.00
18.0~21.0


Mechanical Properties of Deposited Metal
Test Item
Rm(MPa)
A(%)
Guarantee Value
¡Ý520
¡Ý25


Reference Current (AC, DC+)
Electrode Diameter(mm)
¦Õ2.0
¦Õ2.5
¦Õ3.2
¦Õ4.0
¦Õ5.0
Welding Current (A)
40~80
50~100
70~130
100~160
140~200
