E6010 Carbon Steel Welding Electrodes(2.5mm-5.0mm)
[Search Related Products]
E6010 Mild Steel Welding Electrodes( 2.5mm-5.0mm):
Diameter ¡Á Length (mm)
2.5 ¡Á 300, 2.5 ¡Á 350,
3.2 ¡Á 350, 5.0 ¡Á 450
4.0 ¡Á 400, 5.0 ¡Á 400
Package: 5Kg/box,4boxes/carton
Description:
AWS E6010 is a low-carbon steel electrode with a high titaniume coating and can be used on AC. or DC . It has excellent welding technological properties , the arc is stable ,the spatter is small. The slag viscosity is moderate. It can be used freely . The slag is easy to clean . The welded seam is smooth and easy to restrike the arc.
Application:
Suitable for welding sheet metal structure made of low-carbon steel , such as ships, vehicles, building, and general machinery.
Chemical Composition of Rod(%):
C | Mn | Si | S | P |
¡Ü0.12 | 0.3-0.6 | ¡Ü0.35 | ¡Ü0.035 | ¡Ü0.040 |
Mechanical Properties of Deposited Metal:
Test Item | ¦Òb(MPa) | ¦Òc(MPa) | ¦Äs(%) | Akv(¡ãC)(J) |
Guarantee Value | ¡Ý420 | ¡Ý330 | ¡Ý17 | - |
Recommended Welding Current:
Electrode Diameter(mm) | 2.0 | 2.5 | 3.2 | 4.0 | 5.0 |
Current Range(A) | 40-70 | 50-80 | 80-120 | 150-190 | 180-240 |
