Marine Wastewater Processor
1.Under gravity,the water flow to the equipment,dispose of most of the organic substance in the dirty water in the first,then flow the second oxygen box,then flow to the sediment tank and disposeof the dirty mud,then flow to sterilizer,then flow out through discharging pump.
2.The treated water from equipment is complying with the standard of regulation IMO MEPC.159(55).
3.The serial of products has been passed the test of type approval CCS, EC. And approved by CCS, EC, BV, GL classification.
Performance parameters:
Model
SWCM-
10
15
20
25
30
40
50
60
80
100
120
150
200
250
300
400
LOAD
Average load
£¨L/d£©
840
1190
1540
1890
2310
3080
3780
4480
6020
7700
9100
11200
14700
18200
23100
30800
Peak load
£¨L/h£©
105
149
193
237
289
385
473
560
753
963
1138
1400
1838
2275
2888
3850
Organic load
(kgBOD5/d£©
0.42
0.595
0.77
0.945
1.155
1.54
1.89
2.24
3.01
3.85
4.55
5. 6
7.35
9.10
11.55
15.4
Rated capacity
£¨men£©
10
15
20
25
30
40
50
60
80
100
120
150
200
250
300
400
Max capacity£¨men£©
12
17
22
27
33
44
54
64
86
110
130
160
210
260
330
440
Electricity
AC 380V/50Hz/3¦Õ, AC 415V/50Hz/3¦Õ, AC 440/60Hz/3¦Õ (optional)
Power £¨kW£©
2.5
2.5
2.5
2.5
2.5
3.0
3.0
3.5
4.0
4.0
4.0
6.0
6.0
7.0
9.0
11
External dimension £¨mm£©
L¡ÁW¡ÁH
1510
¡Á
1200
¡Á
1300
1870
¡Á
1200
¡Á
1400
1745
¡Á
1400
¡Á
1525
1935
¡Á
1400
¡Á
1560
1985
¡Á
1500
¡Á
1650
2400
¡Á
1600
¡Á
1700
2410
¡Á
1700
¡Á
1850
2670
¡Á
1700
¡Á
1850
2780
¡Á
1900
¡Á
2050
2795
¡Á
2000
¡Á
2200
3000
¡Á
2000
¡Á
2200
3050
¡Á
2200
¡Á
2300
3600
¡Á
2200
¡Á
2350
3880
¡Á
2400
¡Á
2570
4750
¡Á
2400
¡Á
2570
5950
¡Á
2400
¡Á
2570
weight
Dry weight£¨kg£©
900
1000
1000
1100
1200
1300
1450
1600
1850
2200
2300
2800
3000
3300
3700
4200
Wet weight£¨kg£©
1775
2283
2640
2740
3500
4400
5073
5270
6517
8268
9166
11340
13267
16538
20357
25417
Effluent standard
BOD5¡Û25mg/L, COD¡Û125mg/L, TSS¡Û35mg/L, Coliform¡Û100/100ml, PH6¡«8.5, CL2¡Û0.5mg/L
