Cast Iron Flanged Type Butterfly Valve
[Search Related Products]
Cast Iron Flanged Type Butterfly Valve
1. Standard: DIN 3202
2. Connections: Flanged Type
3. Operation: Hand Lever, Worm Gear, Electric Drive, Pneumatic Drive or Hydraulic Drive.
4. Nominal Pressure: DIN PN10/16
5. Temperature Range: NBR -10℃~+80℃, EPDM -10℃~+120℃.
6. Name of Parts:
|
Body |
Cast Iron |
|
Disc |
Al-Bronze |
|
Stem |
Stainless Steel |
|
Liner |
NBR or EPDM |
7. Specification:
|
IMPA Code |
DN |
A |
E |
H |
H1 |
L |
N |
|
756301 |
50 |
165 |
11 |
118 |
67 |
108 |
70 |
|
756302 |
65 |
185 |
11 |
126 |
74 |
112 |
70 |
|
756303 |
80 |
200 |
11 |
133 |
82 |
114 |
70 |
|
756304 |
100 |
228 |
11 |
147 |
100 |
127 |
70 |
|
756305 |
125 |
254 |
14 |
160 |
112 |
140 |
70 |
|
756306 |
150 |
285 |
14 |
180 |
134 |
140 |
70 |
|
756307 |
200 |
343 |
17 |
204 |
159 |
152 |
70 |
|
756308 |
250 |
405 |
22 |
245 |
195 |
165 |
102 |
|
756309 |
300 |
445 |
22 |
270 |
220 |
178 |
102 |
|
756310 |
350 |
505 |
27 |
315 |
282 |
190 |
125 |
|
756311 |
400 |
565 |
27 |
350 |
307 |
216 |
125 |
|
756312 |
450 |
615 |
36 |
375 |
352 |
222 |
140 |
|
756313 |
500 |
670 |
36 |
415 |
387 |
229 |
140 |
|
756314 |
600 |
780 |
46 |
465 |
452 |
267 |
165 |
Cast Iron Flanged Type Butterfly Valve Drawing:
8. Certificate Available:
