Pressure Vacuum Valve for Cargo Oil Tank
1. Size: DN80， DN100， DN125, DN150, DN200, DN250
2. Nominal Pressure: 0.6 MPA, 1.6 MPA
3. Flange Standard: GB, JIS, DIN, ANSI, BS
4. Valve Body Material: Cast Steel, SUS304, SUS304L, SUS316L
5. Part: Pressure Valve and Vacuum Valve.
6. Opening Pressure of Vacuum Valve: -3.5kPa
7. Opening Pressure of Pressure Valve on the oil tank is 14kPa, on the chemical tank is 20kPa.
8. Intallation: It is installed on the vent pipe of oil tanker and chemicals tanker.
9. Features:
(1). When loading the liquid cargo or ballast, the pressure valve in the high velocity relief will open, then jet out combustible liquid cargo vapour/air-mixture in liquid cargo tank with the rate of more than 30m/s, and dilute in the air so that it will never drop on the deck.
(2). When unloading the liquid cargo, the vacuum valve in the high velocity relief valve will open, then supply air to cabin safely so as to avoid the cabin is over-vacuumed.
(3). When the tank navigate on sea, the high velocity valve can automatically adjust the pressure oscillation in the cabin which caused by temperature change.
The Available Certificate of Pressure Vacuum Valve for Cargo Oil Tank :
