Fire Water Monitor
Fire water monitor is fire extinguishing equipment which sprays water to put out the distant fire. It is widely used for petrochemical industries, storage tank areas,hangars, warehouses, ports etc. It is also the best choice for marine ships, fixed offshore platforms, fire trucks and other places.Water monitor has different types with different functions and shapes. It includes advanced automatic water monitor, automatic water monitor, movable water monitor, electric fire monitor, manual operation fire monitor etc. We can provide the customized fire monitor as you request. Therefore,if you¡¯re interested in our fire monitor, please do not hesitate to contact us.
Features of Water Monitor:
1. Support positioning;
2. Wide pressure range;
3. Long jetting distance;
4. Lightweight, small size;
5. Support both horizontal and pitch rotation;
6. Adjustable flow rate and wide discharging range;
7. Full-featured and excellent extinguishing effect
Technical Parameters:
Model |
PS20-50 |
PS60-100 |
||||||
Working Pressure (MPa) |
0.8-1.0 |
0.9-1.2 |
||||||
Flow Rate(L/S) |
20 |
30 |
40 |
50 |
60 |
70 |
80 |
100 |
Jetting Range(m) |
¡Ý48 |
¡Ý55 |
¡Ý60 |
¡Ý65 |
¡Ý70 |
¡Ý75 |
¡Ý80 |
¡Ý85 |
Rotation Angle |
360¡ã |
360¡ã |
||||||
Elevation Angle |
-70¡ã~ +90¡ã |
-70¡ã~ +90¡ã |
||||||
Inlet Flange |
80 |
100 |
Fire Water Monitors:
Advanced Water Monitor:
Stainless Steel Fire Monitor:
Movable Fire Monitor:
Fixed Water Monitor:
Automatic Fire Fighting Monitor:
