60kg Single Type Air Balancer

60kg Single Type Air Balancer

The working principle of air balancer is the practical application of pneumatic control technology. The pneumatic transmission is stable, even the load changes, the working speed of it is stability. It applies to the situation that has demand for smooth transportation, such as aircraft, spaceflight, automobile, precision machinery eauipment, fragile, explosive products production, processing, lifting, etc.

1. Model: 60kg single type air balancer

2. Power source: Compressed air

3. Usage: Hoist

4. Working Pressure: 0.7 Mpa

5. Lifting Height: 1.4m

6. Capacity: 60kg

7. Air Consumption: 0.27m³/min

8. Product Weight: 25kg

9. Packaging: Gunny bag or carton then on steel pallet

10. Special specification and marks can be made according to order quantity

1. Positioning accuracy and the function of elastic floating.

2. Simple adjustment, small working entensity, high efficiency.

3. Low air consumption, ruuning clean without oil.

4. Strong power, solid structure, low noise.

Sketch of Single Type Air Balancer
