High quality Pneumatic Chain Hoist

High Quality Pneumatic Chain Hoist

By pneumatic motor, pneumatic chain hoist transforms the pressure of compressing air into mechanical energy. The precise conponents of it, such as motor and piston, are processed and manufactured by foreign high-precision center. And the chain is made by T8 grade, ageing resistant slloy steel. So, it is suitable for complex, dangerous and limited working place.

Producct details:

1. Minimum capacity: 0.125T: maximum capacity: 0.98T

2. Standard lift height: 3m

3. Usage: lifting, fixing, binding, traction and so on.

4. The main parts of it adopt high quality steel product to ensure durability.

5. Special specifications and marks can be made according to customers requirement.

Safety notice:

1. Please check hooks, wire rope, wheel bearings and other accessories before use.

2. Do not over weight used.

3. Do not expose the hoist in rain or very humid place.

4. Strictly prohibit people to work under it when it working.

5. Gear and spring should be maintained regularly to prevent brake failure.

6. Please select the appropriate tonnage of block according to the weight of the load.

Specification:

Capacity(T)	0.125	0.25	0.5	0.98
Lifting height(m)	3	3	3	3
Air pressure(mpa)	0.6	0.6	0.6	0.6
Motor power(kw)	0.75	0.75	0.75	0.75
Weight(kg)	23	23	23	29.5

High quality Pneumatic Chain Hoist

Sketch of the pneumatic chain hoist
