Fluorescent Wall Light
[Search Related Products]
Fluorescent Wall Light:
Fluorescent Wall Light is one kind of marine lighting system,it is the auxiliary lighting mounted on the interior walls,applied to illumination of dry cabin,such as the residence,retiring room,dining room,cab,operator of the sailors and passengers.The lampshade is plug-in type,and has fine contact function,it made of good quality organic,not discolor,fine toughness,softness ray etc.
Specification:
Type |
Power |
Voltage |
Weight |
Protection Class |
L |
L1 |
ZYB15-1 |
1*15W |
110V/60Hz 220V/50Hz 220V/60Hz |
4.2kg |
IP34 |
521 |
343 |
ZYB15-1E |
4.21kg |
IP34 |
521 |
343 |
||
ZYB20-1 |
1*20W |
4.6kg |
IP34 |
671 |
500 |
|
ZYB20-1E |
4.61kg |
IP34 |
671 |
500 |
||
ZYB30-1 |
1*30W |
5.15kg |
IP34 |
976 |
810 |
|
ZYB30-1E |
5.16kg |
IP34 |
976 |
810 |
||
ZYB40-1 |
1*40W |
5.4kg |
IP34 |
1281 |
810 |
|
ZYB40-1E |
5.41kg |
IP34 |
1281 |
810 |
Wall Light Drawing
