Marine Dual-torch Stud Welding Machine
[Search Related Products]
Marine Dual-torch Stud Welding Machine
Brief Introduction:
1. The stud welding machine can widely use for (marine field) shipbuilding.
2. Board thickness: ¡Ý 3 mm.
3. Welding stud: M4mm-M50mm.
4. Current: 200A-5000A
5. Welding Material: Carbon Steel, Stainless Steel, Copper etc.
6. High speed, safe, light weight, easy to operate and maintain.
Specification:
Item |
RSN7-2500-2 |
RSN7-3150-2 |
RSN7-4000-2 |
RSN7-5000-2 | ||||
operation situation | one gun | dual guns | one gun | dual guns | one gun | dual guns | one gun | dual guns |
welding range | ¦µ6-¦µ28 | ¦µ4-¦µ18 | ¦µ6-¦µ36 | ¦µ4-¦µ20 | ¦µ6-¦µ46 | ¦µ4-¦µ24 | ¦µ8¨C¦µ50 | ¦µ6¨C¦µ28 |
welding current | 400A-2500A | 300A-1250A | 400A-3150A | 300A-1550A | 600A-4000A | 400A-2000A | 600A-5000A | 400A-2500A |
welding speed |
¦µ28 8pcs/minute |
¦µ18 8pcs/minute |
¦µ36 8pcs/minute |
¦µ20 8pcs/minute |
¦µ46 8pcs/minute |
¦µ24 8pcs/minute |
¦µ50 6pcs/minute
|
¦µ28 6pcs/minute |
welding time | 0.1S-3S | 0.1S-3S | 0.1S-3S | 0.1S-3S | ||||
input power | AC 3˜300V-440V | AC 3˜300V-440V | AC 3˜300-440 | AC 3˜300-440 | ||||
rated input power | 90KW | 120KW | 150KW | 190KW | ||||
power switch | 160A | 225A | 250A | 250A | ||||
protect grade | Ip23 | Ip23 | Ip23 | Ip23 | ||||
cooling way | F | F | F | F | ||||
dimension(L/W/H) |
960x418x760mm |
990x418x800mm |
990x418x800mm |
990x418x800mm | ||||
weight | 168KG |
180KG |
188KG | 198KG |
