Mobile Foam fire extinguisher device

Mobile Foam fire extinguisher device

This kind of fire extinguisher consists of the foam maker (foam gun), foam proportioner (foam proportioning unit), fire hose, foam concentrate storage tank, foam monitor / nozzle and the trolley. It is mobile, flexible and easy to move, operate, so it has been widely used in oil industries, museums, airports, bus and railway stations workshops / warehouses as well as other places where there is a fire hazard.

Product detail:

Agent: Foam

Ration of Foam: 3%-6%

Working Pressure: 0.5-1.2MPa

Capacity: 100/200/300/400/500L

Hose Color: White

Rate of Flow: 4L/S, 8L/S

Model Number: Py4

Certificate: ISO, CCC

Place of Origin: Chongqing China (Mainland)

Export Markets: Global

Mobile Foam fire extinguisher device parameter

Model	Working Pressure(Mpa)	Rate Of Flow(L/S)		Jetting Time(s)
Model	Working Pressure(Mpa)	PQ4	PQ8	PQ4	PQ8	PQ4&PQ8
50L	0.5-1.2	4	8	7	3.5	2.3
100L				14	7	4.5
200L				28	14	9
300L				41.5	20.5	13.5
400L				55.5	27.5	18
500L				69.5	34.5	23

photo of Mobile Foam fire extinguisher device

Mobile Foam fire extinguisher device
