Rubber Belt Abrasive Blasting Plant
[Search Related Products]
Q32 series rubber belt abrasive blasting plant is used for surface cleaning, rust removing and surface intensification of various middle and small-size casting, forging and workpieces. It is suitable for different production scale and can also be used in conjunction with the continuous conveyor components to form the production of clean-up lines.
Q32 series rubber belt abrasive blasting plant has the advantages of advanced design, reasonable structure, little energy consumption and high efficiency. It is the ideal blast cleaning equipment for machines.
Technical Details:
Parameter |
Unit |
Q326 |
Q3210 |
QR3210 |
Productivity |
T/H |
0.6-1.2 |
3-5 |
1.5-2.5 |
Loading Weight |
kg |
200 |
800 |
600 |
Maximum Weight |
kg |
10 |
15 |
30 |
Diameter of the Roller |
mm |
650 |
1000 |
1000 |
Available Capacity |
|
0.15 |
0.4 |
0.3 |
Pill Impelling Volume |
kg/min |
100 |
250 |
250 |
Power Air Volume |
|
2200 |
6000 |
5000 |
Power Dissipation |
kw |
12.6 |
32.6 |
24.3 |
Outline Dimensions |
mm |
3681*1650*5800 |
3644*2926*5856 |
3972*2600*4768 |
Machine Total Weight |
kg |
2340 |
5843 |
7400 |
