Ungalvanized and Galvanized Steel Wire Rope 6×37

Ungalvanized and Galvanized Steel Wire Rope 6*37

Ungalvanized and galvanized steel wire rope 6×37 has advantages of high strength, light weight, smooth work and not easy to suddenly broken. Because of its unique properties, a better product hasn’t found at home and aboard to replace it fully or in a field.

Product Details:

1. Item: Ungalvanized and galvanized steel wire rope

2. Construction: 6*37

3. Type: steel wire rope

4. Tensile Strength: 1570, 1670, 1770, 1870, 1960 Mpa.

5. Finish: Galvanized or ungalvanized

6. Material: Steel

7. Usage: Pulling, lifting and transportion

Safety Notice:

1. In operation, the wire rope should be in steady speed

2. Never overload, and never shock load a wire rope

3. Wire rope should be inspected regularly, including abrasion of wire rope, condition of broken wire and metal parts

4. It is important to clean and replace lubricant to the wire rope periodically.

Specification:

Nominal Diameter(mm)	Approx.Weight(kg/100m)		Tensile Strength of Rope(Mpa)
			1570		1670		1770		1870		1960
			Mininum Breaking Load of Rope(KN)
	FC	IWS	FC	IWS	FC	IWS	FC	IWS	FC	IWS	FC	IWS
5	8.65	10	11.6	12.5	12.3	13.3	13.1	14.1	13.8	14.9	14.5	15.6
6	12.5	14.4	16.7	18	17.7	19.2	18.8	20.3	19.9	21.5	20.8	22.5
8	22.1	25.6	29.6	32.1	31.5	34.1	33.4	36.1	35.3	38.2	37	40
10	34.6	40	46.3	50.1	49.3	53.3	52.2	56.5	55.2	59.7	57.8	62.5
12	49.8	57.6	66.7	72.1	70.9	76.7	75.2	81.3	79.4	85.9	83.3	90
14	67.8	78.4	90.8	98.2	96.6	104	102	111	108	117	113	123
16	88.6	102	119	128	126	136	134	145	141	153	148	160
18	112	130	150	162	160	173	169	183	179	193	187	203
20	138	160	185	200	197	213	209	226	221	239	231	250
22	168	194	224	242	238	258	253	273	267	289	280	303
24	199	230	267	289	284	307	301	325	318	344	333	360
26	234	270	313	339	333	360	353	382	373	403	391	423
28	271	314	363	393	386	418	409	443	433	468	453	490
30	311	360	417	451	443	480	470	508	497	537	520	563
32	354	410	474	513	505	546	535	578	565	611	592	640
34	400	462	535	579	570	616	604	653	638	690	668	723
36	448	518	600	649	639	690	677	732	715	773	749	810
38	500	578	669	723	711	769	754	815	797	861	835	903
40	554	640	741	801	788	852	835	903	883	954	925	1000
42	610	706	817	884	869	940	921	996	973	1052	1020	1100
44	670	774	897	970	954	1031	1011	1093	1068	1155	1120	1210
46	732	846	980	1060	1040	1130	1100	1190	1170	1260	1220	1320
48	797	922	1070	1150	1140	1230	1200	1300	1270	1370	1330	1440
50	865	1000	1160	1250	1230	1330	1310	1410	1380	1490	1450	1560
52	936	1080	1250	1350	1330	1440	1410	1530	1490	1610	1560	1690
54	1010	1170	1350	1460	1440	1550	1520	1650	1610	1740	1690	1820
56	1090	1250	1450	1570	1550	1670	1640	1770	1730	1870	1810	1960
58	1160	1350	1560	1680	1660	1790	1760	1900	1860	2010	1950	2100
60	1250	1440	1670	1800	1770	1920	1880	2030	1990	2150	2080	2250
62	1330	1540	1780	1920	1890	2050	2010	2170	2120	2290	2220	2400
64	1420	1640	1900	2050	2020	2180	2140	2310	2260	2440	2370	2560
66	1510	1740	2020	2180	2150	2320	2270	2460	2400	2600	2520	2720
68	1600	1850	2140	2320	2280	2460	2410	2610	2550	2760	2670	2890
70	1700	1960	2270	2450	2410	2610	2560	2770	2700	2920	2830	3060
72	1790	2070	2400	2600	2550	2760	2710	2930	2860	3090	3000	3240
74	1890	2190	2540	2740	2700	2920	2860	3090	3020	3270	3170	3420
76	2000	2310	2680	2890	2850	3080	3020	3260	3190	3450	3340	3610
78	2110	2430	2820	3050	3000	3240	3180	3440	3360	3630	3520	3800
80	2210	2560	2960	3200	3150	3410	3340	3610	3530	3820	3700	4000

Ungalvanized and Galvanized Steel Wire Rope 6×37

Sketch of the ungalvanized and galvanized steel wire rope 6*37

Ungalvanized and Galvanized Steel Wire Rope 6×37
