7-Inch TFT Dual-Frequency Fish Finder

7-Inch TFT Dual-Frequency Fish Finder

7-Inch TFT Dual-Frequency Fish Finder has the advantages of high power, high sensitivity, and low noise. The most distinct feature of this fish finder is that it has extraordinarily strong anti-interference capability. It can effectively eliminate the interference from neighboring ships. Besides, It equips high sensitive transducer which has the maximum power in 6-inch/7-inch fish finders. This fish finder is easy to install, and there are two installation methods: flush-mounted installation, hanging-mount installation.

Features

▪ Strong anti-interference capability

▪ Dual-frequency

▪ 7¡¯¡¯ liquid crystal display

▪ To equip high sensitive transducer

▪ High power

Specifications

Project

Data

Display

7¡¯¡¯ TFT/ 480¡Á234 pixels

Frequency

50KHz, 200KHz, 50/200KHz

Basic Range

1.6~400m

Auto Range

Yes

TX Power

600W

Echo Intensity

8 colors/ 12 colors

Alarm

Shallow water alarm, fish alarm

Alarm Mode

flushing, buzzer

Zoom Mode

bottom-lock zoom, layer zoom

Waterproof

IP52

Overall Dimension

L188¡Á W65 ¡Á H166mm

Power Supply

DC 11~40V
