Speed Log

Speed Log

This speed log adopts the Doppler Effect theory to measure speed and voyage. The 7¡¯¡¯ liquid crystal display can show longitudinal velocity, voyage and distance. This product has high reliability and accuracy, and its appearance is stylish. Besides, it has personalized interface, advanced technology and simple operation. If you want to know more details, please feel free to contact us.

Features

▪ High accuracy

▪ High performance signal filter

▪ Dual-beam system

▪ Stainless steel transceiver cabinet

▪ Liquid crystal display

Specifications

Project

Data

Display

7¡¯¡¯ TFT

Pixel

480¡Á234pixels

STW Speed

arrow+digital speed display

Data Output

IEC61162-1 VBW,VLW

Trip Counter

0-9999.99 nm

Total Counter

0-999999.99nm

Distance Accuracy

0.2nm

Speed Accuracy

0.2kn

Speed Range

-10-+40kn

Power Supply

AC 110/220V 50/60Hz

Operation Temperature

-15-+55¡æ, 0-40¡æ recommended

Humidity

When 40¡À3¡æ, 93¡À2% relative

Protection

Displayer IP23

Controller IP23

Transceiver IP56
