Fresh Water Hydrophore Unit

[Search Related Products]

Fresh Water Hydrophore Unit

1. Hydrophore unit description:

The fresh water hydrophore unit used for vessel washing. There with double high quality strong pressre pumps (one for stand-by), pressure gauge, pressure gauge valve, safety valve, pressure switch, etc.

Fresh Water Hydrophore Unit

2. Main technical parameters:

1). Volume: 0.12-3.0m3

2). Working pressure: 0.4Mpa-0.6MPa

3). Design pressure:0.4Mpa- 0.7MPa

4). Strength test pressure: 1.05MPa

5). Air tightness test pressure: 0.875MPa

6). Open pressure of safety valve: 0.63MPa

Model

Volume(m3)

Design Pressure(Mpa)

Working Pressure(Mpa)

Water Pump Model

Motor Power(kw)

Capacity(m3/h)

Pressure(Mpa)

ZYG-0.12

0.12

0.4~0.7

0.4~0.6

1.5CWX-2

(optional)

2.2 (optional)

3

0.4

ZYG-0.3

0.3

ZYG-0.5

0.5

ZYG-1.0

1.0

ZYG-1.5

1.5

ZYG-2.0

2.0

ZYG-3.0

3.0

3. Warranty: 12 month

Quantity be approved by IMO, all kinds class certificate can be supply.
