Roller Rubber Fender
Roller Rubber Fenders are commonly installed along the walls of dry docks and other restricted channels to help guide vessels and prevent hull damage. Roller fenders are also used on berth corners and lock entrance where lower energy capacity is required.
Feature:
1.Widely used in ports and docks;
2.Agile-turning, easy-installation.
Specification:
Specification
|
Usually Maximum(mm) |
Usually Maximum Burthen (T) |
Energy Absorption (T-m) |
D1-060-20 |
125 |
7 |
0.25 |
D1-075-25 |
157 |
11 |
0.48 |
D1-090-30 |
184 |
15 |
0.88 |
D1-120-40 |
260 |
27 |
1.96 |
D1-150-50 |
325 |
43 |
3.84 |
D1-180-60 |
390 |
62 |
6.63 |
D1-210-70 |
455 |
84 |
10.7 |
D1-240-80 |
520 |
110 |
15.7 |
D2-060-20 |
125 |
14 |
0.5 |
D2-075-25 |
157 |
21 |
1.0 |
D2-090-30 |
184 |
31 |
1.7 |
D2-120-40 |
260 |
55 |
3.9 |
D2-150-50 |
325 |
86 |
7.7 |
D2-180-60 |
390 |
124 |
13.3 |
D2-210-70 |
455 |
169 |
21.0 |
D2-240-80 |
520 |
220 |
32.0 |
D3-060-20 |
125 |
21 |
0.7 |
D3-075-25 |
157 |
32 |
1.4 |
D3-090-30 |
184 |
46 |
2.5 |
D3-120-40 |
260 |
82 |
6.0 |
D3-150-50 |
325 |
128 |
11.0 |
D3-180-60 |
390 |
185 |
20.0 |
D3-210-70 |
455 |
252 |
32.0 |
D3-240-80 |
520 |
329 |
47.0 |
Standard Size of Roller Rubber Fender Type D1
Specification and size \Item |
A |
B |
C |
D |
E |
F |
D1-060-20 |
600 |
200 |
320 |
110 |
420 |
695 |
D1-075-25 |
750 |
250 |
400 |
140 |
510 |
870 |
D1-090-30 |
900 |
300 |
480 |
165 |
610 |
1040 |
D1-120-40 |
1200 |
400 |
640 |
220 |
820 |
1380 |
D1-150-50 |
1500 |
500 |
800 |
275 |
1010 |
1740 |
D1-180-60 |
1800 |
600 |
960 |
330 |
1210 |
2080 |
D1-210-70 |
2100 |
700 |
1155 |
385 |
1410 |
2440 |
D1-240-80 |
2400 |
800 |
1280 |
440 |
1610 |
2770 |
Standard Size of Roller Rubber Fender Type D2
Specification and size \Item |
A |
B |
C |
D |
E |
F |
D2-060-20 |
600 |
200 |
320 |
110 |
770 |
695 |
D2-075-25 |
750 |
250 |
400 |
140 |
935 |
870 |
D2-090-30 |
900 |
300 |
480 |
165 |
1120 |
1040 |
D2-120-40 |
1200 |
400 |
640 |
220 |
1500 |
1380 |
D2-150-50 |
1500 |
500 |
800 |
275 |
1850 |
1740 |
D2-180-60 |
1800 |
600 |
960 |
330 |
2215 |
2080 |
D2-210-70 |
2100 |
700 |
1155 |
385 |
2590 |
2440 |
D2-240-80 |
2400 |
800 |
1280 |
440 |
2950 |
2770 |
Roller Rubber Fender Picture
