Continuous Composite Glass Wool Ceiling
[Search Related Products]
Continuous Composite Glass Wool Ceiling
Our company is specialized in exporting marine decorative material. This type A composite glass wool panel is used as marine ceiling board. It is made with steel sheet or PVC/PET on the surface and glass wool in the core. Our glass wool ceiling is fire resistant and the fire protection rating is B-15 or B-0. Certificates like CCS, BV, DNV, GL, KR, and NK can be offered according to customer¡¯s request.
Features:
1. Ship ceiling board
2. Fire proof rating: B-15, B0
3. Surface finish: PVC/PET film laminated or galvanized steel sheet
4. Core material: glass wool
5. Light weight, perfect function
6. Certificates: CCS, BV, DNV, GL, NK, KR, RINA, etc.
Specifications: |
|||
Model |
T50A |
T30A |
T25A |
Thickness |
50mm |
30mm |
25mm |
Fire endurance rating |
B-15 |
B-0 |
B-0 |
Dimension |
550/600mm width, required length ( max.3600mm) (customized size available) |
||
Plane material |
Galvanized steel sheet with PVC/PET film laminated |
||
Core material |
Glass wool |
Glass wool |
Glass wool |
Weight |
13.7kg/m2 |
10.9kg/m2 |
10.5 kg/m2 |
Sound reduction |
32dB(A) |
31dB(A) |
30dB(A) |
Thermal transmittance |
0.49 kcal/m2h・¡æ |
0.92 kcal/m2h・¡æ |
1.01 kcal/m2h・¡æ |
Tolerances |
Width(-1, 0), length¡À3, thickness(-1,0) |
Product displaying:
Type A Continuous Composite Glass Wool Ceiling Board
