Mooring Chock CB*34-76
Mooring chock, welded on deck or bulwark, is used to guide and control the mooring ropes to a certain direction. Its surface is polished smoothly in order to reduce the friction of the rope. CB*34-76 marine mooring chocks have four types: CB34-76 type A, type B, type C, type D. If you¡¯re interested in our mooring chocks, please feel free to contact us.
Specification :
Model Type: CB*34-76 Type C
Material: Cast Steel
Weight: 37.5kg~296kg
Standard: CB*34-76
Certificate: CCS,DNV,ABS,BV,LR,RS,KR
Drawing of Mooring Chock CB 34-76 Type C:
Unit:mm
Steel Rope Dia |
Hemp Rope C |
Nylon Rope Dia |
L |
L1 |
B |
B1 |
B2 |
B3 |
H |
H1 |
R |
R1 |
b1 |
b2 |
b3 |
r |
r1 |
r2 |
r3 |
t1 |
t2 |
Weight(kg) ¡Ö |
15.0 |
125 |
30 |
150 |
400 |
110 |
170 |
118 |
60 |
250 |
115 |
48 |
102 |
32 |
40 |
26 |
50 |
27 |
20 |
10 |
25 |
5 |
37.5 |
18.5 |
160 |
35 |
200 |
500 |
150 |
190 |
139 |
71 |
317 |
146 |
65 |
133 |
40 |
50 |
32 |
70 |
30 |
30 |
10 |
30 |
5 |
63.0 |
22.5 |
200 |
45 |
250 |
600 |
190 |
220 |
161 |
82 |
382 |
177 |
85 |
165 |
45 |
55 |
30 |
75 |
37 |
30 |
15 |
35 |
10 |
97.0 |
28 |
230 |
55 |
300 |
650 |
220 |
250 |
172 |
88 |
436 |
198 |
95 |
203 |
50 |
60 |
42 |
90 |
37 |
40 |
15 |
40 |
10 |
127.0 |
38 |
270 |
70 |
400 |
750 |
290 |
280 |
185 |
95 |
513 |
240 |
125 |
273 |
55 |
65 |
47 |
95 |
39 |
40 |
20 |
45 |
10 |
210.0 |
43.5 |
325 |
90 |
500 |
880 |
350 |
300 |
199 |
102 |
589 |
277 |
147 |
350 |
60 |
70 |
51 |
110 |
42 |
50 |
20 |
50 |
10 |
296.0 |
