Carbon Steel Wire Rope Sleeve
Carbon steel wire rope sleeve is made from specially processed low-carbon alloy steel. It is conforming to ASME B30.9, all sling with swage sockets shall be tested for proof load. And it is suitable for the lifting job where the joint is under wear abrasion and under extrusion.
Product Details:
1. Model: Carbon steel wire rope sleeve
2. Material: Low-carbon alloy steel
3. Shape: Oval shape
4. Usage: Wire rope fitting
5. Size: 8mm-32mm
6. Packaging: Gunny bag or carton then on steel pallet
7. Special specification and marks can be made according to order quantity
Specification:
Code |
Weight |
L |
B |
C |
D |
lbs/100pcs |
mm |
mm |
mm |
mm |
|
SH-08 |
17 |
31.75 |
27.43 |
20.57 |
4.83 |
SH-10 |
13 |
31.75 |
28.45 |
20.57 |
3.56 |
SH-11 |
331 |
41.4 |
35.81 |
25.91 |
4.83 |
SH-13 |
27 |
41.4 |
36.58 |
25.91 |
4.06 |
SH-14 |
63 |
57.15 |
43.69 |
31.24 |
5.84 |
SH-16 |
54 |
57.15 |
46.74 |
32.51 |
5.08 |
SH-19 |
90 |
66.8 |
54.86 |
38.61 |
5.84 |
SH-22 |
126 |
73.15 |
63.5 |
44.45 |
6.86 |
SH-26 |
187 |
77.72 |
72.14 |
50.8 |
8.38 |
SH-32 |
384 |
103.12 |
88.9 |
63.5 |
9.65 |
Sketch of carbon steel wire rope sleeve
Various Carbon Steel Wire Rope Sleeve
