Hot Rolled Bulb Flats

Hot Rolled Bulb Flats

Bulb flats is a kind of steel sections with an optimum weight ratio. They are used in shipbuilding as plate stiffeners in different fields of application. Their shape guarantees many advantages compared with other reinforcement solutions: first, bulb flats are the most economical reinforcement for plates; second, they have obvious advantages in strength to weight ratio than other possible reinforcement; their shape reduce welding to minimum during installation... The hot rolled bulb flats are made of marine steel certified by leading classification societies, such as CCS, ABS, BV, LR, GL... They are produced by Chinese top steel mills which have mature technology, strict quality management and rich production experience. The bulb flats meet requirements of GB/T 9945-2012 or EN 10067. If you are interested in our hot rolled bulb flats, welcome to contact us. Customization is available.

The following table shows steel grades that we provide regularly for bulb flats:

Adopted Standard

Steel Grades

ABS Grade

AB/A, AB/AN, AB/B, AB/BN, AB/D, AB/DN, AB/E, AB/EN, AB/AH32, AB/AH32N, AB/DH32, AB/DH32N, AB/EH32, AB/EH32N, AB/AH36, AB/AH36N, AB/DH36, AB/DH36N, AB/EH36, AB/EH36N, AB/AH40, AB/AH40N, AB/DH40, AB/DH40N, AB/EH40, AB/EH40N

BV Grade

BVA, BVB, BVD, BVE, BVAH32, BVDH32, BVEH32, BVAH36, BVDH36, BVEH36, BVAH40, BVDH40, BVEH40

CCS Grade

CCSA, CCSB, CCSD, CCSE, CCSAH32, CCSDH32, CCSEH32, CCSAH36, CCSDH36, CCSEH36, CCSAH40, CCSDH40, CCSEH40

DNV Grade

NV A, NV B, NV D, NV E, NV A32, NV D32, NV E32, NV A36, NV D36, NV E36, NV A40, NV D40, NV E40

GL Grade

GL-A, GL-ATM, GL-B, GL-BTM, GL-D, GL-DTM, GL-E, GL-ETM, GL-A32, GL-A32TM, GL-D32, GL-D32TM, GL-E32, GL-E32TM, GL-A36, GL-A36TM, GL-D36, GL-D36TM, GL-E36, GL-E36TM, GL-A40, GL-A40TM, GL-D40, GL-D40TM, GL-E40, GL-E40TM

KR Grade

KRA, KRB, KRD, KRE, KRAH32, KRDH32, KREH32, KRAH36, KRDH36, KREH36, KRAH40, KRDH40, KREH40

LR Grade

LRA, LRB, LRD, LRE, LRAH32, LRDH32, LREH32, LRAH36, LRDH36, LREH36, LRAH40, LRDH40, LREH40

NK Grade

KA, KB, KD, KE, KA32, KD32, KE32, KA36, KD36, KE36,, KA40, KD40, KE40

RINA Grade

RINA-A, RINA-B, RINA-D, RINA-E, RINA-AH32, RINA-DH32, RINA-EH32, RINA-AH36, RINA-DH36, RINA-EH36, RINA-AH40, RINA-DH40, RINA-EH40

Hot Rolled Bulb Flats

/photos/Parameters-of-GB-9945-Hot-Rolled-Bulb-Flats.docx

Hot Rolled Bulb Flats

/photos/Parameters-of-EN10067-Hot-Rolled-Bulb-Flats.docx


Hot Rolled Bulb Flats

Hot Rolled Bulb Flats

Hot Rolled Bulb Flats

Hot Rolled Bulb Flats

Hot Rolled Bulb Flats
