Hot-Rolled Flat Sections for Shipbuilding

[Search Related Products]

Hot-Rolled Flat Sections for Shipbuilding

Hot-Rolled Flat Sections for Shipbuilding

Hot-rolled flat sections for shipbuilding are a kind of section steel which are applied to shipbuilding. We can provide you the hot-rolled flat sections for shipbuilding as following dimensions: thickness in the range of 3~60mm, breadth in the range of 10 to 400mm, and customized length. Besides, we also provide you full selection of steel grades Q235, Q345, A36, SS400... The hot-rolled flat sections for shipbuilding are manufactured under exacting standards. The flat sections feature little tolerance, well-shaped and light in weight. If you have any specific requirements, we can customize products for you to some extent. If you are interested in our flat sections, please feel free to contact us. We will reply you soon.

Our Advantages

• Best quality products

• An ample supply

• To support customization

• Delivery on time

• Rich experience in import and export trade

Product Details

Project

Data

Material

Q235, Q345, S235, S275 or as customers¡¯ requirements

Standards

GB/T 702-2008

Process

Hot rolling

Sizes

Thickness: 3~60mm

Breadth: 10~400mm

Length: as per customized

Hot-Rolled Flat Sections for Shipbuilding

Drawing of Hot-Rolled Flat Sections

Some Available Dimensions

Model

Nominal Dimensions

Breadth

Thickness

Radius

FS75

75

7~16

¨Q3

FS80

80

7~16

¨Q3

FS100

100

8~16

¨Q3

FS120

120

8~16

¨Q3

FS150

150

9~20

¨Q3

FS200

200

10~25

¨Q4

FS250

250

10~25

¨Q4

FS300

300

12~30

¨Q5

FS350

350

12~30

¨Q5

FS400

400

15~35

¨Q5

Measurement Allowance

Project

Tolerance

Thickness (mm)

t<6

-0.3~+1.0

6¨Qt<12

-0.3~+0.8

12¨Qt<15

-0.3~+0.5

t¨R15

¡À0.3

Breadth (mm)

b<100

¡À1.5

100¨Qb<150

¡À2.0

150¨Qb<300

¡À2.5

b¨R300

¡À3.5

Length (mm)

0~+80

Hot-Rolled Flat Sections for Shipbuilding

Hot-Rolled Flat Sections for Shipbuilding

Hot-Rolled Flat Sections for Shipbuilding

Hot-Rolled Flat Sections for Shipbuilding

Hot-Rolled Flat Sections for Shipbuilding
