Marine Hot Rolled Flat Steel
Marine hot rolled flat steel is a kind of section steel which is applied to shipbuilding. We can provide you the marine hot rolled flat steel as following dimensions: thickness in the range of 3~60mm, breadth in the range of 10 to 400mm, and customized length. Besides, we also provide you full selection of steel grades Q235, Q345, A36, SS400... The marine hot-rolled flat steel is manufactured under exacting standards. The flat steel features little tolerance, well-shaped and light in weight. If you have any specific requirements, we can customize products for you to some extent. If you are interested in our flat sections, please feel free to contact us. We will reply you soon.
Our Advantages
• Best quality products
• An ample supply
• To support customization
• Delivery on time
• Rich experience in import and export trade
Product Details
Project |
Data |
Material |
Q235, Q345, S235, S275, SS400, A36 or as customers¡¯ requirements |
Standards |
GB/T 702-2008 |
Process |
Hot rolling |
Dimensions |
Thickness: 3~60mm Breadth: 10~400mm Length: as per customized |
Drawing of Marine Hot Rolled Flat Steel
Some Available Dimensions
Model |
Nominal Dimensions |
||
Breadth |
Thickness |
Radius |
|
FS75 |
75 |
7~16 |
¨Q3 |
FS80 |
80 |
7~16 |
¨Q3 |
FS100 |
100 |
8~16 |
¨Q3 |
FS120 |
120 |
8~16 |
¨Q3 |
FS150 |
150 |
9~20 |
¨Q3 |
FS200 |
200 |
10~25 |
¨Q4 |
FS250 |
250 |
10~25 |
¨Q4 |
FS300 |
300 |
12~30 |
¨Q5 |
FS350 |
350 |
12~30 |
¨Q5 |
FS400 |
400 |
15~35 |
¨Q5 |
Measurement Allowance
Project |
Tolerance |
|
Thickness (mm) |
t<6 |
-0.3~+1.0 |
6¨Qt<12 |
-0.3~+0.8 |
|
12¨Qt<15 |
-0.3~+0.5 |
|
t¨R15 |
¡À0.3 |
|
Breadth (mm) |
b<100 |
¡À1.5 |
100¨Qb<150 |
¡À2.0 |
|
150¨Qb<300 |
¡À2.5 |
|
b¨R300 |
¡À3.5 |
|
Length (mm) |
0~+80 |
